ASDSP-6
Review: 0
Rp3.200.000
Get questions answered fast & free! Call us
- 081-123-456-789
ASDSP-6
ASDSP-6
SPECIFICATION :
- 6 Channel DSP Amplifier
- Dynamic range < 100dB
- Signal to Noise (RCA) > 95 dB
- Total ramp distortion < 0.1%
- Input Voltage High level: 12V:RCA:500mV
- Output voltage High level: 28Vpp: RCA:2.82Vpp
- Power rating 6CHx25W(4Q,14.4V, 1kHz, 1%THD)
- Maximum power 6CHX35W(40,14.4V, 1 kHz, 10%THD)
- Input/output sensitivity (RCA) 1:2(without power amplification)
- Frequency Response 20Hz~20KHz
- System sample rate 48kHz/24bit
- Input Impedance High level: 1002; RCA:22k2
- Operating voltage 8-18V
- Standby current ImA
- REM start input ACC or High level
- REM start output 3-18V
- Start-up time 5S
- Operating ambient temperature -20-60° C
- Storage temperature -40-85° C
- Net weight 1,1 kg
- Size 189mmx 140mmx49mm
